مشخصات، دیتاشیت، قیمت و خرید LH0041G

LH0041G نمایش بزرگتر
LH0041G

کد کالا: 48050

نو (جدید)

دسته‌بندی: تقویت کننده خطی - آپ امپ ها

توجه: آخرین موجودی فعلی!

National Semiconductor, 1.0 Amp Power Operational Amplifier

جزییات بیشتر

فروشنده: : سيليكون
تعداد محصولات: 3122
طرفداران: 12
تاریخ افتتاح: 1400-11-24

موجودی انبار: 1 قلم

7,597,700 ریال

دانلود

ویژگی های: LH0041G

مشخصات کلی

نوع عملکرد(Function Type) : آپ امپ

اطلاعات بیشتر

آی سی LH0041G یک آپ امپ ( تقویت کننده ) عمومی با قابلیت جریان دهی بالا می باشد.
The LH0021/LH0021C and LH0041/LH0041C are general purpose operational amplifiers capable of delivering large output currents not usually associated with conventional IC Op Amps. The LH0021 will provide output currents in excess of one ampere at voltage levels of g 12V; the LH0041 delivers currents of 200 mA at voltage levels closely approaching the available power supplies. In addition, both the inputs and outputs are protected against overload. the devices are compensated with a single external capacitor and are free of any unusual oscillation or latch-up problems.

The excellent input characteristics and high output capability of the LH0021 make it an ideal choice for power applications such as DC servos, capstan drivers, deflection yoke drivers, and programmable power supplies.

The LH0041 is particularly suited for applications such as torque driver for inertial guidance systems, diddle yoke driver for alpha-numeric CRT displays, cable drivers, and programmable power supplies for automatic test equipment.

The LH0021 is supplied in a 8 pin TO-3 package rated at 20 watts with suitable heatsink.
